Description :
Electrofusion welding is widely used in PE and PP pipe jointing, with various kind of electrofusion fittings. With the tool of electrofusion welder, the connection job can be done efficiently. Our MEF & EFM series electrofusion welder can provide flexible choice of welding, ranging from 20mm to 315mm, EFM Electrofusion Machine Exporter in India, EFM Electrofusion Machine Manufacturer.
MATRIX INDUSTRIES had been developing, manufacturing and distributing thermoplastic welding equipment since 2021. It's our pleasure to help you build reputation in the piping project.
Product Characteristics :
- Control core of high lever MCU, for accurate welding control
- Built-in Voltage stabilizer, for steady welding
- Industrial level electrical parts, for steady performance
- Over-load protection design, guarantee safe operation
Technical Specifications :
| Welding mode | Automatic and Manual | Automatic and Manual |
| Welding range (mm) | 20-160 | 20-315 |
| Suitable material | PE, PP | PE, PP |
| Power Supply | 200V-250V/50Hz, 1 PH | 200V-250V/50Hz, 1 PH |
| Total Power | 1.6 KW | 2.2 KW |
| Ambient temperature | -15~45℃ | -15~45℃ |
| Voltage control mode | 8~48V adjustable | 8~48V adjustable |
| Current control mode | 1~60A | 1~60A |
| Time adjusting range | 1-9999 seconds | 1-9999 seconds |
| Data interface | scanner | scanner |
| Input Supply Cable | 3 Meter | 3 Meter |
| Fusion Cable | 3 Meter | 3 Meter |
| Connecting pin | 4 & 4.7 mm One pair | 4 & 4.7 mm One pair |
| Generator Required | 5 KVA | 5 KVA |
| Net Weight of Machine | 15 KG | 16 KG |
